GDC™ Voice Announcement Air Shower - 1200(W)x1500(D)x2200(H)

Find Similar Products

GDC™ Voice Announcement Air Shower - 1200(W)x3000(D)x2200(H)

US$900.00-4500.00
Min. Order:1 unit
GDC™ Voice Announcement Air Shower - 1200(W)x2000(D)x2200(H)

US$900.00-4500.00
Min. Order:1 unit
GDC™ Voice Announcement Air Shower - 1200(W)x1500(D)x2200(H)

US$900.00-4500.00
Min. Order:1 unit
GDC™ Intelligent voice air shower - 1200(W)x1000(D)x2200(H)

US$900.00-4500.00
Min. Order:1 unit
GDC™ Voice Announcement Air Shower - 1400(W)x3000(D)x2200(H)

US$900.00-4500.00
Min. Order:1 unit
GDC™ Intelligent voice air shower - 1400(W)x2000(D)x2200(H)

US$900.00-4500.00
Min. Order:1 unit

Product information Company lnfo.

Detail
Parameter
Structure
Usage

Air Shower Detail

The Auto Sensor Air Shower is a high-efficiency cleanroom equipment designed to remove particulate matter and contaminants from personnel and materials before they enter clean environments. Equipped with advanced sensor technology, the Auto Sensor Air Shower automatically detects the presence of personnel or objects, initiating and ceasing the air shower process to ensure efficient and energy-saving operation.

Deiiang air shower playbill.jpg

Features

Automatic Sensing: Infrared/ultrasonic sensors for automatic operation
High-Efficiency Filtration: HEPA/ULPA filters capture 99.97%+ particles ≥ 0.3 microns
Programmable Control: Touchscreen/PLC for setting parameters
Omnidirectional Nozzles: Multi-angle, high-velocity air jets
Emergency Stop: Immediate cessation for safety
Stainless Steel: Durable, corrosion-resistant construction
Interlocking Doors: Prevents cross-contamination
Low-Noise Design: Quiet operation for user comfort

Industry Applications

Electronics Manufacturing: Semiconductor and microelectronics
The Auto Sensor Air Shower is a high-efficiency cleanroom equipment designed to remove particulate matter and contaminants from personnel and materials before they enter clean environments. Equipped with advanced sensor technology, the Auto Sensor Air Shower automatically detects the presence of personnel or objects, initiating and ceasing the air shower process to ensure efficient and energy-saving operation.
Features
Industry Applications
Pharmaceuticals: Drug manufacturing and packaging

Electronics Manufacturing: Semiconductor and microelectronics
Pharmaceuticals: Drug manufacturing and packaging
Food Processing: High hygiene standards in production
Biotechnology: Labs and production facilities
Aerospace: Manufacturing and assembly
Automotive: Painting and assembly processes
Automatic Sensing: Infrared/ultrasonic sensors for automatic operation
High-Efficiency Filtration: HEPA/ULPA filters capture 99.97%+ particles ≥ 0.3 microns
Programmable Control: Touchscreen/PLC for setting parameters
Omnidirectional Nozzles: Multi-angle, high-velocity air jets
Emergency Stop: Immediate cessation for safety
Stainless Steel: Durable, corrosion-resistant construction
Interlocking Doors: Prevents cross-contamination
Low-Noise Design: Quiet operation for user comfort

Food Processing: High hygiene standards in production
Biotechnology: Labs and production facilities
Aerospace: Manufacturing and assembly
Automotive: Painting and assembly processes

Stainless steel air shower room10.jpg

Stainless steel air shower room6.jpg

Stainless steel air shower room9.jpg

Air shower room details2.jpg

Air shower room details1.jpg

Air Shower Parameter

Indicator Model	1`Purifier STD	2`Purifier STD	3`Purifier STD	4`Purifier STD	5`Purifier STD
Material Selection	1.2mm high quality cold rolled disease plate baking paint, outside steel plate baking paint inside stainless steel SUS304 stainless steel inside and outside (double doors and floor are SUS304 stainless steel pot)
Number of applicants	1 person	2 persons (affordable)	3.4 persons (2 persons standard)	3.4 persons (3 persons standard)	6.8 persons (4 persons standard)
Number of nozzles	12 (bilateral)	18 (bilateral)	24 (bilateral)	36 (bilateral)	48 (bilateral)
Air velocity	24-30m/s	24-30m/s	24-30m/s	24-30m/s	24-30m/s
Electronic lock brand	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks
Efficient size	600x600x120mm	820x600x120mm	600x600x120mm	600x600x120mm	600x600x120mm
Overall Dimension	1400W1000D2100H	1400W1500D2100H	1400W2000D2100H	1400W3000D2100H	1400W4000D2100H
Internal dimensions	800w900D1960H	800w1400D1960H	800w1900D1960H	800w2900D1960H	800w3900D1960H
power supply	380V, 50Hz (three-phase five-wire power supply, three fires, one connection and one ground). The air shower room can be customized with 220V and 110V power supply according to customers' requirements.)
Lighting	LED recessed light 1pc	LED recessed light 2pc	LED recessed light 2pc	LED recessed light 3pc	LED recessed light 4pc
Number of fans	2 sets "0.55Kw/set	2 sets~0.75KW/set	4 units "0.55Kw/unit	6 sets "0.55KW/set	8 units*0.55Kw/unit
Power of the whole machine	1.1Kw	1.5Kw	2.2Kw	3.3Kw	4.4Kw
Stall capacity (kg)	350kg	500kg	650kg	950kg	1250kg

Indicator Model	1`Purifier STD	2`Purifier STD	3`Purifier STD
Material Selection	1.2mm high quality cold rolled disease plate baking paint, outside steel plate baking paint inside stainless steel SUS304 stainless steel inside and outside (double doors and floor are SUS304 stainless steel pot)
Number of applicants	1 person	2 persons (affordable)	3.4 persons (2 persons standard)
Number of nozzles	12 (bilateral)	18 (bilateral)	24 (bilateral)
Air velocity	24-30m/s	24-30m/s	24-30m/s
Electronic lock brand	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks
Efficient size	600x600x120mm	820x600x120mm	600x600x120mm
Overall Dimension	1400W1000D2100H	1400W1500D2100H	1400W2000D2100H
Internal dimensions	800w900D1960H	800w1400D1960H	800w1900D1960H
power supply	380V, 50Hz (three-phase five-wire power supply, three fires, one connection and one ground). The air shower room can be customized with 220V and 110V power supply according to customers' requirements.)
Lighting	LED recessed light 1pc	LED recessed light 2pc	LED recessed light 2pc
Number of fans	2 sets "0.55Kw/set	2 sets~0.75KW/set	4 units "0.55Kw/unit
Power of the whole machine	1.1Kw	1.5Kw	2.2Kw
Stall capacity (kg)	350kg	500kg	650kg

Indicator Model	3`Purifier STD	4`Purifier STD	5`Purifier STD
Material Selection	1.2mm high quality cold rolled disease plate baking paint, outside steel plate baking paint inside stainless steel SUS304 stainless steel inside and outside (double doors and floor are SUS304 stainless steel pot)
Number of applicants	3.4 persons (2 persons standard)	3.4 persons (3 persons standard)	6.8 persons (4 persons standard)
Number of nozzles	24 (bilateral)	36 (bilateral)	48 (bilateral)
Air velocity	24-30m/s	24-30m/s	24-30m/s
Electronic lock brand	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks
Efficient size	600x600x120mm	600x600x120mm	600x600x120mm
Overall Dimension	1400W2000D2100H	1400W3000D2100H	1400W4000D2100H
Internal dimensions	800w1900D1960H	800w2900D1960H	800w3900D1960H
power supply	380V, 50Hz (three-phase five-wire power supply, three fires, one connection and one ground). The air shower room can be customized with 220V and 110V power supply according to customers' requirements.)
Lighting	LED recessed light 2pc	LED recessed light 3pc	LED recessed light 4pc
Number of fans	4 units "0.55Kw/unit	6 sets "0.55KW/set	8 units*0.55Kw/unit
Power of the whole machine	2.2Kw	3.3Kw	4.4Kw

Indicator Model	1`Purifier STD	2`Purifier STD	3`Purifier STD	4`Purifier STD	5`Purifier STD
Material Selection	1.2mm high quality cold rolled disease plate baking paint, outside steel plate baking paint inside stainless steel SUS304 stainless steel inside and outside (double doors and floor are SUS304 stainless steel pot)
Number of applicants	1 person	2 persons (affordable)	3.4 persons (2 persons standard)	3.4 persons (3 persons standard)	6.8 persons (4 persons standard)
Number of nozzles	12 (bilateral)	18 (bilateral)	24 (bilateral)	36 (bilateral)	48 (bilateral)
Air velocity	24-30m/s	24-30m/s	24-30m/s	24-30m/s	24-30m/s
Electronic lock brand	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks
Efficient size	600x600x120mm	820x600x120mm	600x600x120mm	600x600x120mm	600x600x120mm
Overall Dimension	1400W1000D2100H	1400W1500D2100H	1400W2000D2100H	1400W3000D2100H	1400W4000D2100H
Internal dimensions	800w900D1960H	800w1400D1960H	800w1900D1960H	800w2900D1960H	800w3900D1960H
power supply	380V, 50Hz (three-phase five-wire power supply, three fires, one connection and one ground). The air shower room can be customized with 220V and 110V power supply according to customers' requirements.)
Lighting	LED recessed light 1pc	LED recessed light 2pc	LED recessed light 2pc	LED recessed light 3pc	LED recessed light 4pc
Number of fans	2 sets "0.55Kw/set	2 sets~0.75KW/set	4 units "0.55Kw/unit	6 sets "0.55KW/set	8 units*0.55Kw/unit
Power of the whole machine	1.1Kw	1.5Kw	2.2Kw	3.3Kw	4.4Kw
Stall capacity (kg)	350kg	500kg	650kg	950kg	1250kg

Indicator Model	1`Purifier STD	2`Purifier STD	3`Purifier STD
Material Selection	1.2mm high quality cold rolled disease plate baking paint, outside steel plate baking paint inside stainless steel SUS304 stainless steel inside and outside (double doors and floor are SUS304 stainless steel pot)
Number of applicants	1 person	2 persons (affordable)	3.4 persons (2 persons standard)
Number of nozzles	12 (bilateral)	18 (bilateral)	24 (bilateral)
Air velocity	24-30m/s	24-30m/s	24-30m/s
Electronic lock brand	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks
Efficient size	600x600x120mm	820x600x120mm	600x600x120mm
Overall Dimension	1400W1000D2100H	1400W1500D2100H	1400W2000D2100H
Internal dimensions	800w900D1960H	800w1400D1960H	800w1900D1960H
power supply	380V, 50Hz (three-phase five-wire power supply, three fires, one connection and one ground). The air shower room can be customized with 220V and 110V power supply according to customers' requirements.)
Lighting	LED recessed light 1pc	LED recessed light 2pc	LED recessed light 2pc
Number of fans	2 sets "0.55Kw/set	2 sets~0.75KW/set	4 units "0.55Kw/unit
Power of the whole machine	1.1Kw	1.5Kw	2.2Kw
Stall capacity (kg)	350kg	500kg	650kg

Indicator Model	3`Purifier STD	4`Purifier STD	5`Purifier STD
Material Selection	1.2mm high quality cold rolled disease plate baking paint, outside steel plate baking paint inside stainless steel SUS304 stainless steel inside and outside (double doors and floor are SUS304 stainless steel pot)
Number of applicants	3.4 persons (2 persons standard)	3.4 persons (3 persons standard)	6.8 persons (4 persons standard)
Number of nozzles	24 (bilateral)	36 (bilateral)	48 (bilateral)
Air velocity	24-30m/s	24-30m/s	24-30m/s
Electronic lock brand	"Luxgen" electric locks	"Luxgen" electric locks	"Luxgen" electric locks
Efficient size	600x600x120mm	600x600x120mm	600x600x120mm
Overall Dimension	1400W2000D2100H	1400W3000D2100H	1400W4000D2100H
Internal dimensions	800w1900D1960H	800w2900D1960H	800w3900D1960H
power supply	380V, 50Hz (three-phase five-wire power supply, three fires, one connection and one ground). The air shower room can be customized with 220V and 110V power supply according to customers' requirements.)
Lighting	LED recessed light 2pc	LED recessed light 3pc	LED recessed light 4pc
Number of fans	4 units "0.55Kw/unit	6 sets "0.55KW/set	8 units*0.55Kw/unit
Power of the whole machine	2.2Kw	3.3Kw	4.4Kw
Stall capacity (kg)	650kg	950kg	1250kg

Air Shower Structure

Stainless steel air shower room configuration structure

Air shower room structure diagram.jpg

Top cover
Door closer
Suction cup lock
Lighting
Control panel
Emergency switch
Stainless steel door
Stainless steel nozzle
High efficiency filter
Box
Primary filter
Specialized fan
Stainless steel chassis

Air Shower Usage

Air Shower Room Operation Steps

How to use the air shower

Prepare:

Ensure you are properly attired in cleanroom garments.
Verify that the air shower is operational.

Enter:

Step into the air shower room and close the door behind you.
Stand in the designated area and remain still.

Activate:

Wait for the air shower cycle to start automatically.
The air jets will begin, removing contaminants.

Exit:

After the cycle completes, open the exit door.

FAQ

1. Intelligent voice air shower energy consumption

The energy consumption of an intelligent voice air shower varies depending on its size, usage frequency, and features. Typically, these systems are designed to be energy-efficient while maintaining optimal performance in decontamination processes.

2. Intelligent voice air shower for hospital use

Hospitals utilize intelligent voice air showers to maintain sterile environments, especially in areas like operating rooms and cleanrooms. These systems help reduce the risk of infection by removing contaminants from personnel and equipment before they enter critical areas.

3. Intelligent voice air shower cleaning protocols

Cleaning protocols for intelligent voice air showers include regular wiping of surfaces, filter maintenance, and periodic system checks. Adhering to these protocols ensures the longevity and efficiency of the air shower, maintaining a contaminant-free environment.

4. Intelligent voice air shower sensor technology

Intelligent voice air showers use advanced sensor technology to detect the presence of personnel and activate the decontamination process. These sensors ensure that the air shower operates efficiently and only when needed, conserving energy and resources.

5. Intelligent voice air shower safety features

Safety features in intelligent voice air showers include emergency stop buttons, interlock systems, and voice-guided instructions. These features ensure user safety and prevent accidental exposure to contaminants during the decontamination process.

6. Intelligent voice air shower installation requirements

Installing an intelligent voice air shower requires adequate space, proper ventilation, and access to electrical power. Additionally, the installation should comply with local building codes and industry standards to ensure safe and effective operation.

7. Intelligent voice air shower for laboratories

In laboratories, intelligent voice air showers help maintain a contaminant-free environment. They are particularly useful in biosafety labs and research facilities, where preventing contamination is critical for experiments and data integrity.

8. Intelligent voice air shower alarm systems

Intelligent voice air showers are equipped with alarm systems to alert users of any malfunctions or safety breaches. These alarms can include visual and audible signals, ensuring that issues are promptly addressed to maintain operational integrity.

Visual signals
Audible alerts

9. Intelligent voice air shower installation guide

The installation guide for an intelligent voice air shower provides step-by-step instructions on setting up the unit. It includes details on site preparation, electrical connections, and initial system testing to ensure proper functionality.

10. Intelligent voice air shower leasing options

Leasing options for intelligent voice air showers provide a cost-effective solution for businesses. Leasing allows companies to use the latest technology without significant upfront investment, with options for upgrading or purchasing the system at the end of the lease term.

11. Intelligent voice air shower voice command features

Voice command features in intelligent voice air showers allow users to operate the system hands-free. These features enhance convenience and hygiene by reducing the need for physical contact with the unit.

12. Intelligent voice air shower software updates

Regular software updates for intelligent voice air showers ensure that the system remains up-to-date with the latest features and security protocols. These updates can be automatically installed or manually initiated, depending on the system configuration.

13. How does an intelligent voice air shower work?

An intelligent voice air shower works by using high-velocity air jets to remove contaminants from personnel and equipment. The system is activated by sensors or voice commands, which trigger a timed decontamination cycle, ensuring thorough cleaning before entry into a cleanroom.

14. Intelligent voice air shower for single user

Single-user intelligent voice air showers are compact and efficient, providing individualized decontamination. They are ideal for small cleanrooms or facilities with limited space, ensuring thorough cleaning of each person.

15. Intelligent voice air shower door options

Intelligent voice air showers come with various door options, including automatic, manual, and sliding doors. These options accommodate different space constraints and user preferences, ensuring ease of access and optimal functionality.

16. Intelligent voice air shower remote monitoring

Remote monitoring features in intelligent voice air showers allow facility managers to oversee operations from a distance. This capability includes monitoring system performance, receiving alerts, and making adjustments as needed to ensure continuous efficiency.

17. Intelligent voice air shower for paint booths

In paint booths, intelligent voice air showers help remove dust and particulates from personnel, ensuring a clean environment for painting operations. This results in higher-quality finishes and reduced contamination of painted surfaces.

18. Intelligent voice air shower operational efficiency

Operational efficiency in intelligent voice air showers is achieved through advanced sensor technology, energy-efficient components, and automated processes. These features ensure effective decontamination with minimal resource consumption.

Advanced sensors
Energy-efficient components
Automated processes

19. Intelligent voice air shower control panel

The control panel of an intelligent voice air shower provides users with easy access to system settings and operational controls. It includes features such as touchscreens, status indicators, and emergency stop buttons for safe and efficient use.
