1` FYCLS Negative Pressure Raw Material Dispensing Room - Wind Speed Sensor, Wind Pressure Sensor, Frequency Converter

Product Description:

A negative pressure weighing room is a type of localized purification equipment used in specific areas such as pharmaceuticals, microbiological research and scientific experiments.

Send email to us

Download as PDF

How to Work With Us

Submit Requirements

Provide your site dimensions, required ISO class, and industry-specific needs (GMP, ESD, etc.) to our experts.

Custom Technical Proposal

Receive a detailed design proposal within 24 hours, including airflow strategies, material lists, and transparent pricing.

Modular Production

We manufacture your modular panels, HVAC units, and FFUs with strict QC to ensure full compliance with ISO 14644 standards.

Global Shipping & Setup

Fast global logistics followed by onsite installation guidance and performance validation to get you operational quickly.

FAQ

Negative Pressure Weighing Chamber Specifications	KLDC-FYCLS 1200	KLDC-FYCLS 1300	KLDC-FYCLS 1400	KLDC-FYCLS 1500	KLDC-FYCLS 1600	KLDC-FYCLS 2700
Overall Dimension(mm)	1200X1200x2500	1300X1300X2500	1500x1300X2500	2000x1300Xx2500	2000X1500X2500	2000x1800X2500
Size of working area (mm)	1100X700X2000	1200x800X2000	1400X700X2000	1900x800X2000	1900X1000X2000	1900X1300X2000
Rated air volume (m°/h)	1300~1500	1600~1800	2000~2200	2500~2700	3400-3600	4500~4900
Wind speed (m/s)	0.45+20%	0.45+20%	0.45+20%	0.45+20%	0.45+20%	0.45+20%
cleanliness level	A级	A级	A级	A级	A级	A级
Noise (dB)	72	72	72	72	72	72
Illumination (Lux)	>300	>300	>300	>300	>300	>300
control method	Inverter Control LCD control	Inverter Control LCD control	Inverter Control LCD control	Inverter Control LCD control	Inverter Control LCD control	Inverter Control LCD control
Power (KW)	0.75	0.75	1.5	1.5	2.2	2.2

Note: Negative pressure weighing room can be made according to customer requirements for non-standard products.　

Fan system: long-life, low-noise, maintenance-free, low-vibration fans are used to ensure stable operation for a long time.
Double-layer negative pressure structure: the unique double-layer design effectively avoids the risk of leakage and ensures the sealing of the internal environment.
Excellent performance of even air distribution: well-designed air duct system ensures even air distribution in the whole working area.
Air speed adjustment: The air speed can be adjusted by automatic constant or stepwise adjustment to meet different experimental requirements.
Liquid Tank Design: Unique liquid tank design ensures perfect sealing effect and prevents any possible contamination.
Consistency of internal and external structure: The internal and external structure is designed to be neat and free of dead corners, which is easy to clean and maintain.
Wind speed frequency conversion system: manual wind speed frequency conversion system ensures that the wind speed in the main working area is always uniform.
Filter differential pressure display device: real-time monitoring of the operating conditions of each filter channel to ensure filtration efficiency.
Unique air duct design: effectively control the working noise of the whole machine and provide a quiet working environment.
Even flow design: Even flow design in the main working area controls the spillage and upward movement of dust and reagents to protect the operator and the environment.
Operation area protection: Hundred levels of vertical laminar flow protection, in line with international standards ISO 5 (NF, EN, ISO 14644-1).
Use of the environment and conditions: suitable for temperature 5 ° C - 40 ° C, relative humidity is not greater than 85% (non-condensing), the atmospheric pressure of 86kPa-106kPa environment, the power supply AC380v, three-phase, 50HZ.
Box material: made of SUS304# sanded stainless steel, thickness 1.0MM, to ensure the stability and durability of the structure.
