Reference Price:US$from $1500

Short Description:

Ultra-clean bench, also known as clean bench, is a unidirectional flow type air purification equipment used to provide a localized dust-free and sterile working environment. It is widely used in medical, scientific research, optoelectronics and other industries, especially indispensable in research and production departments that require a localized clean and sterile working environment. It is a device that integrates a variety of advanced technologies and is designed to provide the necessary clean environment guarantee for production and research activities in specific fields. Whether from the point of view of design, working principle or scope of application, the ultra-clean bench embodies the pursuit of high efficiency, high precision and high standard of modern industry. With the continuous progress of technology, the ultra-clean bench is also constantly updated to meet the increasingly stringent cleanliness requirements.

Air Flow: Vertical flow
Available sizes: 7 ft
size: 2100×850×1500
Operating surface: One-sided
Internal height: 2 ft
Cleanbench Air Filter: ULPA Filter
Power Supply Configuration: 115V、20A North America、230V British (UK)、230V China/Australia、230V India、230V Schuko、230V 100V、 20A
Applicable area: USA Europe Malaysia Canada Middle East Indonesia
Customs code: 8421399090

Send email to us Download as PDF

Cleanroom

7 ft Vertical Laminar Flow Cabinet

Choose your installation & validation options below

None
Validation
Installation & Validation

Quantity:

Choose your upgrade options

1 x 6x3m Trunking for CR6
1 x 6x3m Flooring Kit for CR6
1 x S/S Step Over Bench Open One side (400x400x 800mm) - 6C
1 x Stainless Steel Waste Bin - Freestanding Ring
1 x S/S Table: No Shelf - No Upstand 1200X600mm
1 x Bimos Labsit 2 with castors - Blue

Quantity:

Summary

Cleanroom

7 ft Vertical Laminar Flow Cabinet

Choose your installation & validation options below

Validation

Installation & Validation

Choose your upgrade options

1 x 6x3m Trunking for CR6

1 x 6x3m Flooring Kit for CR6

1 x S/S Step Over Bench Open One side (400x400x 800mm) - 6C

1 x Stainless Steel Waste Bin - Freestanding Ring

1 x S/S Table: No Shelf - No Upstand 1200X600mm

1 x Bimos Labsit 2 with castors - Blue

Send email to us Download as PDF

Find Similar Products

Product information Company lnfo.

Detail
Features
ProductPrinciple
Accessories

Product Briefing

A 3 ft Vertical Laminar Flow Cabinet is a specialized piece of laboratory equipment designed to provide a clean and controlled environment for various applications, such as microbiological research, pharmaceuticals, and semiconductor manufacturing. Here’s a detailed overview of its features, functions, and benefits:

laminar flow hoods Product Poster .jpg

Applications

Microbiology: Ideal for working with cultures, cell lines, and other sensitive biological materials.
Pharmaceuticals: Used in the preparation and compounding of sterile medications.
Electronics: Suitable for assembling and handling sensitive electronic components that may be susceptible to dust or static.
Research: Provides a clean environment for various scientific experiments and procedures.

Models

Vertical Laminar Flow Clean Bench
Model	GDC-SPT-01	GDC-SPT-02	GDC-SPT-03
	3 ft	4ft	5ft
External size W×D×H(mm)	1000×850×1500	1200×850×1500	1500×850×1500
Internal Size W×D×H(mm)	960×600×600	1160×600×600	1460×600×600
HEPA Filter(mm)	905×585×69×1 Pcs	1105×585×69×1 Pcs	1405×585×69×1 Pcs
HEPA Filter Efficiency	99.95%@0.3μm	99.95%@0.3μm	99.95%@0.3μm
G4 Pre Filter(mm)	500×375×21×1 Pcs	500×375×21×1 Pcs	745×375×21×1 Pcs
Noise	52～62dB（A）	52～62dB（A）	52～62dB（A）
Fan Pressure	260pa	260pa	260pa
Fan Power (W)	200W×1 Pcs	200W×1 Pcs	200W×1 Pcs
LED Lamp Power(W)	12W×1 Pcs	18W×1 Pcs	30W×1 Pcs
Air Velocity(m/s)	0.45m/s±20%
Clean Level	ISO 5
Supply Power	AC 1N 220V/50Hz
Control System	4.3"touch screen,3 stage regulation,light,sterilization

Vertical Laminar Flow Clean Bench
Model	GDC-SPT-01	GDC-SPT-02	GDC-SPT-03
	3 ft	4ft	5ft
External size W×D×H(mm)	1000×850×1500	1200×850×1500	1500×850×1500
Internal Size W×D×H(mm)	960×600×600	1160×600×600	1460×600×600
HEPA Filter(mm)	905×585×69×1 Pcs	1105×585×69×1 Pcs	1405×585×69×1 Pcs
HEPA Filter Efficiency	99.95%@0.3μm	99.95%@0.3μm	99.95%@0.3μm
G4 Pre Filter(mm)	500×375×21×1 Pcs	500×375×21×1 Pcs	745×375×21×1 Pcs
Noise	52～62dB（A）	52～62dB（A）	52～62dB（A）
Fan Pressure	260pa	260pa	260pa
Fan Power (W)	200W×1 Pcs	200W×1 Pcs	200W×1 Pcs
LED Lamp Power(W)	12W×1 Pcs	18W×1 Pcs	30W×1 Pcs
Air Velocity(m/s)	0.45m/s±20%
Clean Level	ISO 5
Supply Power	AC 1N 220V/50Hz
Control System	4.3"touch screen,3 stage regulation,light,sterilization

Features

	High-Quality Construction Stainless steel worktop Spill-retaining design will ensure containment of accidental liquid spills
	Quiet Operation Comfortable low noise at 52 dBA Reduce fatigue and improve work concentration
	ULPA Filter 10x Filtration efficiency of HEPA filter Creates ISO Class 3 work zone instead of industry-standard ISO Class 5
	Energy-efficient Powered by latest generation DC ECM blower, that is more efficient than legacy ECM and VFD motors 70% Energy savings compared to AC motor Stable airflow, despite building voltage fluctuations & filter loading
	GDC™ Antimicrobial Powder Coating Eliminates 99.9% of surface bacteria within 24 hours of exposure

Principle

Air Intake: Ambient air is drawn into the cabinet through an intake grille.
Filtration: The air passes through a HEPA filter, removing 99.97% of particles ≥0.3 microns.
Laminar Airflow: Filtered air is directed vertically downward in a smooth, uninterrupted flow.
Clean Workspace: The downward airflow creates a contamination-free zone, protecting the work area and materials.
User Safety: The design minimizes exposure to airborne contaminants, enhancing operator safety.
Maintained Pressure: The cabinet maintains a slight negative pressure to prevent external contaminants from entering.
Consistent Environment: Provides a stable and sterile environment for sensitive applications.

Ultra-clean bench working principle.jpg

Accessories

Stainless Steel Orifice Tabletop
ULPA Ultra GX Filter
UV Germicidal Lamps
De-static equipment
Support Stand with Caster Wheels

FAQ

1. How to handle spillages in a vertical flow cleanbench?

In the event of a spillage in a vertical flow cleanbench, immediately stop work and notify all personnel in the vicinity. Use appropriate personal protective equipment (PPE) to clean up the spill, using absorbent materials and disinfectants if necessary. Ensure the airflow is maintained during cleanup to prevent contamination spread.

2. How to calibrate a vertical flow cleanbench?

Calibrate a vertical flow cleanbench by first ensuring it is turned on and has been running for at least 30 minutes. Use an anemometer to measure airflow velocity at various points across the work surface. Adjust the fan speed or replace filters if the airflow is outside the recommended range. Document the calibration results for future reference.

3. How to enhance the filtration efficiency of a vertical laminar flow cabinet?

Enhance the filtration efficiency of a vertical laminar flow cabinet by regularly replacing HEPA or ULPA filters as per the manufacturer's recommendations. Keep the pre-filters clean to reduce load on the main filters. Ensure the cabinet is free from obstructions that could disrupt airflow and reduce filter efficiency.

4. Can a vertical laminar flow cabinet be used for pharmaceutical manufacturing?

Yes, a vertical laminar flow cabinet can be used for pharmaceutical manufacturing. These cabinets provide a sterile environment by filtering out contaminants, which is critical for maintaining the purity and safety of pharmaceutical products. Compliance with industry standards and regular validation are essential for such applications.

5. How to incorporate ergonomic design in vertical flow cleanbenches?

Incorporate ergonomic design in vertical flow cleanbenches by using adjustable stands to accommodate different user heights. Implement anti-fatigue mats and ergonomic chairs to enhance user comfort. Ensure that controls and frequently used items are within easy reach to minimize strain and improve workflow efficiency.

6. What standards regulate vertical flow cleanbenches?

Vertical flow cleanbenches are regulated by standards such as ISO 14644 for cleanrooms and associated controlled environments, and NSF/ANSI 49 for biosafety cabinetry. Adherence to these standards ensures the cleanbench provides the required level of air cleanliness and safety for various applications.

7. What are the benefits of using a vertical laminar flow cabinet?

Vertical laminar flow cabinets provide a controlled environment by filtering out airborne contaminants, ensuring a sterile workspace. They protect sensitive samples and processes from contamination, improve product quality, and enhance safety for laboratory personnel. These cabinets are essential in industries requiring high levels of cleanliness.

8. How to improve the efficiency of a vertical laminar flow cabinet?

Improve the efficiency of a vertical laminar flow cabinet by conducting regular maintenance, including cleaning and filter replacement. Ensure the work area is free from obstructions that could disrupt airflow. Periodically test airflow velocity and adjust as needed to maintain optimal performance.

9. What industries use vertical laminar flow cleanbenches?

Vertical laminar flow cleanbenches are used in various industries, including pharmaceuticals, biotechnology, electronics manufacturing, and research laboratories. These cleanbenches provide a contamination-free environment essential for processes that require high levels of cleanliness and sterility.

10. What are the key features to look for in a vertical flow cleanbench?

Key features to look for in a vertical flow cleanbench include HEPA or ULPA filters for high-efficiency particle removal, adjustable airflow controls, ergonomic design, and easy-to-clean surfaces. Additional features like UV sterilization lights and built-in alarms for filter performance can enhance functionality and safety.

11. How to ensure proper sealing in a vertical laminar flow cabinet?

Ensure proper sealing in a vertical laminar flow cabinet by regularly inspecting door gaskets and seals for wear and tear. Replace any damaged seals promptly. Perform smoke tests to check for leaks and ensure that the cabinet maintains a controlled airflow environment.

12. Can vertical laminar flow cabinets be customized for specific applications?

Yes, vertical laminar flow cabinets can be customized for specific applications. Customizations may include specialized filtration systems, additional safety features, and tailored ergonomic designs. Manufacturers often offer options to meet unique requirements for various industries and research needs.

13. How to measure the effectiveness of a vertical laminar flow cabinet?

Measure the effectiveness of a vertical laminar flow cabinet by conducting regular airflow velocity tests and particle count measurements. Use these metrics to ensure the cabinet maintains the required cleanliness levels. Document all tests and maintenance activities to track performance over time.

14. What is the role of airflow uniformity in vertical flow cleanbenches?

Airflow uniformity in vertical flow cleanbenches is crucial for maintaining a consistent sterile environment. Uniform airflow ensures that contaminants are effectively removed and prevents turbulence that could disrupt the clean air barrier. This uniformity is essential for protecting sensitive processes and samples.

15. What are the environmental benefits of using vertical flow cleanbenches?

Vertical flow cleanbenches provide environmental benefits by reducing the need for extensive cleanroom facilities, thereby lowering energy consumption. They also help minimize waste and contamination, leading to more efficient use of resources and reducing the overall environmental impact of laboratory operations.

16. What materials are used in constructing a vertical laminar flow cabinet?

Vertical laminar flow cabinets are typically constructed from materials such as stainless steel for durability and easy cleaning, and tempered glass for visibility and safety. The use of high-quality HEPA or ULPA filters ensures effective particulate removal, maintaining the sterile environment required for various applications.
